Broadvue 6 Mil Preforated Vinyl

Broadvue 6 Mil Preforated Vinyl

MAGIC BROADVUE is a 6 mil perforated, PVC window vinyl designed for exterior mounted window graphics. BROADVUE has a pattern of round, evenly spaced holes based on a 60/40% perforation allowing exterior mounted graphics to be seen from the outside but appear invisible from the inside.

FEATURES & BENEFITS

  • Removable and repositionable pressure sensitive adhesive
  • Superior water fastness
  • Indoor or outdoor use

COMMON APPLICATIONS

  • Window graphics
  • Door graphics
  • Vehicle graphics
  • General signage
  • Retail advertising
  • Tradeshow and installation graphics

PRINTER COMPATIBILITY




PHYSICAL CHARACTERISTICS
  • Thickness 6 mil
  • Satin Finish
  • Outdoor Life Expectancy 1 year
  • Liner Type PET
  • Adhesive Type Removable
PRODUCT INFO
  • Perforated Window Vinyl
  • Core Size 3" Core
  • 1 Roll per Carton
SHELF LIFE
  • 2 years from ship date
 STORAGE CONDITIONS
  • Temperature 50-85° F (10-30° C)
  • Relative Humidity 30-65%
OPTIMAL PRINTING ENVIRONMENT
  • Temperature 50-85° F (10-30° C)
  • Relative Humidity 30-65%

FINISHING & PRINTING

  • Print on white outside surface
  • Heater settings for solvent / eco solvent: 40 ̊ C - 45 ̊ C
  • Allow to completely dry before finishing
  • If stacking graphics use a silicone sheet between layers
  • Clear liquid laminates provide excellent surface protection
  • Apply to clean dry surface above 40 ̊F
  • Peel and fold back 1” of liner
  • Align to the surface and press the top edge down
  • Peel the remaining liner and use a squeegee to apply
  • Do not stretch
  • Visit www.magicinkjet.com for media profiles
